Instrument for cutting oil slots in spray maker

maker:
Priestman Brothers Limited
Instrument for cutting oil slots in spray maker

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Part of Priestman oil engine: viz one slotting machine - instrument for cutting oil slots in spray maker

Details

Category:
Heat Engines (non steam)
Object Number:
1914-409
Measurements:
overall: 127 mm x 237 mm x 148 mm,
type:
component
credit:
Priestman Bros. Ltd.
