Sir W. Thomson's patent volt balance

Made:
1889 in Glasgow
maker:
James White
Sir W. Thomson's patent volt balance

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Sir W. Thomson's patent volt balance, No.10, made by J. White, Glasgow

Details

Category:
Electricity and Magnetism
Object Number:
1935-323
Measurements:
overall: 570 mm x 500 mm x 500 mm,
type:
balance
credit:
Lt. Col. Sir Francis McClean.
