Oudin resonator with two Leyden jars
- Made:
- 1897-1910
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Oudin resonator with two Leyden jars on wooden stand
Details
- Category:
- Electricity and Magnetism
- Object Number:
- 1933-135
- Materials:
- wood (unidentified), glass, brass (copper, zinc alloy) and bakelite
- Measurements:
-
Large Tube: 260 mm x 710 mm x 260 mm,
Wooden Table: 730 mm x 490 mm x 400 mm,
Small Pipes: 40 mm x 590 mm x 80 mm,
- type:
- resonator
- credit:
- Chapman, A.C.
