EMI 9565 4 1/2 inch Image Orthicon Tube
This image is released under a CC BY-NC-SA 4.0 Licence
Buy this image as a print
BuyLicense this image for commercial use at Science and Society Picture Library
LicenseEMI 9565 4 1/2 inch Image Orthicon Tube, (Elcon target).
Science Museum Group
© The Board of Trustees of the Science Museum
EMI 9565 4 1/2 inch Image Orthicon Tube, (Elcon target).
The 4.5 inch IO (Image Orthicon) tube was developed in the UK based on the RCA-developed 3 inch tube it gave much improved resolution and better picture shading. Although less sensitive than the 3 inch version, it rapidly became the mainstay of monochrome broadcast cameras. The Elcon target was much better than the earlier soda-lime targets and was less prone to "image sticking".
Details
- Category:
- Television
- Collection:
- BBC Heritage Collection
- Object Number:
- 2012-5118/41
- Materials:
- glass, metal (unknown) and electronic components
- Measurements:
-
overall: 115 mm x 495 mm x 115 mm, 115 mm,
- type:
- cathode ray tube
