BBC ATM/1 AC Test Meter
- Made:
- 1960
This image is released under a CC BY-NC-SA 4.0
Licence
Buy this image as a print
BuyLicense this image for commercial use at Science and Society Picture Library
LicenseBBC ATM/1 AC Test Meter
Science Museum Group
© The Board of Trustees of the Science Museum
BBC ATM/1 AC test meter (valve), 1960. The ATM/1 was used as either an amplifier detector or a test programme meter amplifier. A 600-ohm input jack and a high-impedance input jack are provided on the jackfield.
It was a rack-mounted component which formed part of BBC's A.C. Test Bay AC/55, a 19-inch bay of equipment for the audio-frequency testing of sound apparatus and the audio-frequency and direct current testing of lines. At small centres where the full facilites were not required the bay was supplied partially equipped as necessary to suit the requirements of the particular station.
Details
- Category:
- Television
- Collection:
- BBC Heritage Collection
- Object Number:
- 2012-5118/317
- Materials:
- metal (unknown), plastic (unidentified) and electronic components
- Measurements:
-
overall: 155 mm x 490 mm x 230 mm, 8.5 kg
- type:
- meter
