Aircraft wind tunnel model

Made:
Hulme
Aircraft wind tunnel model

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Scale wind tunnel models of HS 748 airliner engine nacelle designs.

Details

Category:
Aeronautics
Object Number:
Y2011.50.13
Materials:
wood (unidentified), metal (unknown), paint, plastic (unidentified), brass (copper, zinc alloy) and lead alloy
Measurements:
overall: 360 mm x 570 mm x 948 mm,
type:
wind tunnel model
