Side Frame of Rotary Printing Press
Top unit, side frame of Rotary Printing Press. Used at South Lancashire Newspapers Ltd, St Helens. manufactured by R, Hoe & Company, London.
Rotary printing press. Dismantled. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
Details
- Category:
- Printing & Writing
- Object Number:
- Y1988.106
- Materials:
- polyurethane, iron and steel (metal)
- type:
- rotary press
- credit:
- Gift of South Lancashire Newspapers Ltd
Parts
Base of Rotary Printing Press. Used at South Lancashire Newspapers Ltd
Base of Rotary Printing Press. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 9700 mm x 3760 mm x 1440 mm,
- Materials:
- iron
- Object Number:
- Y1988.106.2
- type:
- printing press base
Side Frame of Rotary Printing Press
Middle unit, side frame of Rotary Printing Press. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
Drive Shaft of Rotary Printing Press
Drive shaft of Rotary Printing Press. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 540 mm x 540 mm x 2600 mm, 371 kg
- Materials:
- iron
- Object Number:
- Y1988.106.4
- type:
- drive shaft
Drive Shaft of Rotary Printing Press
Drive shaft from Rotary Printing Press. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 220 mm x 220 mm x 1700 mm,
- Materials:
- iron
- Object Number:
- Y1988.106.5
- type:
- drive shaft
Drive Shaft of Rotary Printing Press
Drive shaft from Rotary Printing Press, with paper wrapped around roller. Used at South Lancashire Newspapers Ltd, St Helens.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 230 mm x 230 mm x 1950 mm,
- Materials:
- iron
- Object Number:
- Y1988.106.6
- type:
- drive shaft
Component of Hoe Rotary Printing Press
Large, free-standing part of the Hoe Printing Press machinery with rollers.
- Measurements:
-
overall: 2150 kg
- Materials:
- metal (unknown)
- Object Number:
- Y1988.106.9
- type:
- hoe printing press
Roller for Hoe Rotary Printing Press
Large roller for the Hoe printing press.
- Measurements:
-
overall: 2910 kg
- Materials:
- metal (unknown)
- Object Number:
- Y1988.106.10
- type:
- hoe roller
Components for Hoe Rotary Printing Press
Crate of guards, hand rails, foot boards etc from the Hoe Printing Press.
- Measurements:
-
overall: 1440 mm x 1000 mm x 2160 mm,
- Object Number:
- Y1988.106.11
Base Unit for Hoe Rotary Printing Press
Crate containing the base unit for the Hoe printing press.
Base Component for Hoe Rotary Printing Press
Crate containing the base part for the Hoe printing press.
Top Unit for Hoe Rotary Printing Press
Crate 1/2 containing the top unit for the Hoe printing press.
Cylinders for Hoe Rotary Printing Press
Crate 1/2 containing the middle and base cylinders from the Hoe printing press.
Top Unit for Hoe Rotary Printing Press
Crate 2/2 containing the top unit for the Hoe printing press.
Cylinders for Hoe Rotary Printing Press
Crate 2/2 containing middle and base cylinders for the Hoe printing press.
Panels for Hoe Rotary Printing Press
Two panels from the Hoe printing press.
- Measurements:
-
overall: 150 mm x 1300 mm x 1830 mm, 50.5 kg
- Object Number:
- Y1988.106.18
- type:
- hoe printing press parts
Components for Hoe Rotary Printing Press
Collection of parts for the Hoe printing press, one smaller guard with chain and leather banding and a box of metal fittings. Machine parts.
- Measurements:
-
overall: 500 mm x 400 mm x 600 mm, 68.5 kg
- Object Number:
- Y1988.106.19
- type:
- hoe parts miscellaneous
Roller for Hoe Rotary Printing Press
Roller from the Hoe printing press.
- Measurements:
-
overall: 320 mm x 270 mm x 2550 mm, 97 kg
- Object Number:
- Y1988.106.20
- type:
- hoe roller
Guard for Hoe Rotary Printing Press
Guard for the Hoe printing press.
Guard for Hoe Rotary Printing Press
Large green guard for the Hoe printing press.
- Measurements:
-
overall: 470 mm x 860 mm x 1470 mm, 8.5 kg
- Materials:
- metal (unknown)
- Object Number:
- Y1988.106.22
- type:
- hoe guard
Two parts of printing press frame
Two parts of printing press frame; with drive shaft part, and bolts still attached.
Manufactured by R, Hoe & Company, London.
- Object Number:
- Y1988.106.23
- type:
- printing press part
Hoe Printing Press Frame
Section of Hoe printing press frame; with drive shaft section, and bolts still attached.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 430 mm x 1260 mm x 2600 mm, 420 kg
- Object Number:
- Y1988.106.23/1
- type:
- printing press frame
- Part of:
- Y1988.106.23
Hoe Printing Press Frame
Hoe printing press frame section. Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 150 mm x 1330 mm x 2520 mm, 361 kg
- Object Number:
- Y1988.106.23/2
- type:
- printing press frame
- Part of:
- Y1988.106.23
Twelve Printing Rollers for Rotary Printing Press
twelve printing rollers, for rotary printing press.
Manufactured by R, Hoe & Company, London.
Fifteen Printing Rollers for Rotary Printing Press
fifteen printing rollers, for rotary printing press.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 320 mm x 2050 mm x 865 mm,
- Materials:
- iron
- Object Number:
- Y1988.106.25
- type:
- printing press parts
Newspaper Delivery System
newspaper delivery system; top part, rollers and motor is visible. Used with Hoe Rotary Printing Press
manufactured by Igranic Electric Co Ltd.
- Measurements:
-
overall: 650 mm x 1010 mm x 710 mm,
- Materials:
- steel (metal)
- Object Number:
- Y1988.106.26
Three Legs from Hoe Printing Press
3 legs from Hoe printing press, one of which consists of wheels and handle. 'Certified Max 7 1/2 CWT. Combined Hooks Sept 1960 Todd Bros.' written on each side of 2 of the legs.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 440 mm x 1240 mm x 1330 mm, 329 kg
- Materials:
- cast iron
- Object Number:
- Y1988.106.27
- type:
- printing press parts
Twelve Rollers for Rotary Printing Press
twelve rollers for rotary printing press; two are covered in paper.
Manufactured by R, Hoe & Company, London.
- Measurements:
-
overall: 345 mm x 2200 mm x 980 mm,
- Materials:
- iron
- Object Number:
- Y1988.106.28
- type:
- printing press parts
Hoe Rotary Press Components
Hoe Rotary Press parts- a pallet of parts from rotary press. Various parts including triangle panel with a frame at the back, lineshafts, switch/adjustment board and small machine components.
Manufactured by Hoe, R. & Co.
- Measurements:
-
overall: 1069 mm x 1183 mm x 975 mm, 240 kg
- Materials:
- iron and metal (unknown)
- Object Number:
- Y1988.106.29
- type:
- hoe rotary press parts
Large frame part from Rotary Printing Press
Large frame part from rotary printing press. Used at South Lancashire Newspapers Ltd, St Helens. Manufactured by R, Hoe & Company, London.
Medium frame part from Rotary Printing Press
Medium frame part from rotary printing press. Used at South Lancashire Newspapers Ltd, St Helens. Manufactured by R, Hoe & Company, London. With 3 sheets of metal.
Small frame part from Rotary Printing Press
Small frame part from rotary printing press. Used at South Lancashire Newspapers Ltd, St Helens. Manufactured by R, Hoe & Company, London.
Metal component from Rotary Printing Press
Metal component from rotary printing press. Used at South Lancashire Newspapers Ltd, St Helens. Manufactured by R, Hoe & Company, London.
