Handheld linear array real-time scanner

Made:
1979 in Netherlands
Handheld linear array real-time scanner

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

Buy this image as a print

Buy

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Handheld linear array real-time scanner, MiniVisor, Organon Teknika, Netherlands 1979 in a portable briefcase with manual, charger and ‘Ultra-phonic conductivity gel’ in white bottle with nozzle

Details

Category:
Clinical Diagnosis
Object Number:
2023-473
Materials:
metal, plastic and electronic components
Measurements:
overall (closed case): 175 mm x 430 mm x 350 mm, 10 kg
type:
ultrasound scanner

Parts

Handheld linear array real-time scanner Handheld linear array real-time scanner Handheld linear array real-time scanner Handheld linear array real-time scanner Handheld linear array real-time scanner Handheld linear array real-time scanner Handheld linear array real-time scanner

Handheld linear array real-time scanner

Handheld linear array real-time scanner, MiniVisor, Organon Teknika, Netherlands 1979.

Measurements:
overall: 275 mm x 150 mm x 160 mm,
Materials:
metal , plastic and electronic components
Object Number:
2023-473/1
type:
ultrasound scanner
Image ©
The Board of Trustees of the Science Museum
Charger for Handheld linear array real-time scanner

Charger for Handheld linear array real-time scanner

Charger and cable for handheld linear array real-time scanner, MiniVisor, Organon Teknika, Netherlands 1979.

Materials:
metal , plastic and electronic components
Object Number:
2023-473/2
type:
chargers
Image ©
The Board of Trustees of the Science Museum
Conductivity Gel Handheld linear array real-time scanner Conductivity Gel Handheld linear array real-time scanner Conductivity Gel Handheld linear array real-time scanner

Conductivity Gel Handheld linear array real-time scanner

Ultra-phonic conductivity gel’ in white bottle with nozzle for handheld linear array real-time scanner. Made by Pharmaceutical Innovations Inc.

Measurements:
overall: 183 mm 51 mm,
Materials:
plastic (unidentified)
Object Number:
2023-473/3
type:
gel
Image ©
The Board of Trustees of the Science Museum
Plastic ruler

Plastic ruler

Plastic ruler for handheld linear array real-time scanner, MiniVisor, Organon Teknika, Netherlands 1979.

Measurements:
overall: 4 mm x 34 mm x 92 mm,
Materials:
plastic (unidentified)
Object Number:
2023-473/4
type:
ruler
Image ©
The Board of Trustees of the Science Museum
Case Handheld linear array real-time scanner Case Handheld linear array real-time scanner Case Handheld linear array real-time scanner

Case Handheld linear array real-time scanner

Fitted case for handheld linear array real-time scanner, MiniVisor, Organon Teknika, Netherlands 1979 in a portable briefcase with manual, charger and ‘Ultra-phonic conductivity gel’ in white bottle with nozzle

Materials:
metal and plastic
Object Number:
2023-473/5
type:
case - container
Image ©
The Board of Trustees of the Science Museum
