Silver coated GT-cut quartz plate, with nodal region positioned wires

Silver coated GT-cut quartz plate, with nodal region positioned wires

GT-cut quartz plate, mounted in glass envelope, inside jar

GT-cut quartz plate, mounted in glass envelope, inside jar

GT-cut quartz plate assembled in clamp and ready for insertion into casing. Part of a series of 11 objects demonstrating how a crystal plate or ring is mounted for use in a quartz oscillator.

GT-cut quartz plate assembled in clamp and ready for insertion into casing
