Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise

Made:: 1951

maker:: Jack Pitman

Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise, in order to study brain potentials evoked by sensory stimuli, by Jack Pitman, for George Dawson, University College London, London, England, 1951

Details

Category:: Psychology, Psychiatry & Anthropometry

Object Number:: 1980-1606

Materials:: wood, steel, brass, aluminium and perspex, ? material

Measurements:: overall: 215 x 350 x 720 mm (approximate)

type:: electroencephalograph signal averagers

credit:: University College London

Cite this page

Rights

We encourage the use and reuse of our collection data.

Data in the title, made, maker and details fields are released under Creative Commons Zero . Descriptions and all other text content are licensed under a Creative Commons Attribution 4.0 licence

Using our data

Download

Download catalogue entry as json

Download manifest IIIF

Our records are constantly being enhanced and improved, but please note that we cannot guarantee the accuracy of any information shown on this website.

Parts

Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise

Measurements:: overall: 215 x 350 x 720 mm (approximate)

Materials:: wood , steel , brass , aluminium and perspex, ? material

Object Number:: 1980-1606/1

type:: electroencephalograph signal averagers

Power supply cable

Power supply cable, with black plastic 3-square pin plug at one end and 3-round pin connector at the other end, from Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise, in order to study brain potentials evoked by sensory stimuli, by Jack Pitman, for George Dawson, University College London, London, England, 1951

Materials:: plastic (unidentified) and copper (alloy)

Object Number:: 1980-1606/2

type:: cable

Image ©: The Board of Trustees of the Science Museum

Steel box

Steel box, with six 50mm holes on two sides, from Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise, in order to study brain potentials evoked by sensory stimuli, by Jack Pitman, for George Dawson, University College London, London, England, 1951

Materials:: steel (metal)

Object Number:: 1980-1606/3

type:: box - container

Steel box

Steel box, from Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise, in order to study brain potentials evoked by sensory stimuli, by Jack Pitman, for George Dawson, University College London, London, England, 1951

Materials:: steel (metal)

Object Number:: 1980-1606/4

type:: box - container

Braided textile covered electric cable

Braided textile covered electric cable with elbow connector at one end and straight-line connector at other end, from Prototype analogue signal averager for use in electroencephalography (EEG) to separate EEG signals from noise, in order to study brain potentials evoked by sensory stimuli, by Jack Pitman, for George Dawson, University College London, London, England, 1951

Materials:: textile , steel (metal) , metal (unknown) and plastic (unidentified)

Object Number:: 1980-1606/5

type:: electric cable
