Wooden airscrew blade

Wooden airscrew blade

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Wooden airscrew blade showing stages of manufacture

Details

Category:
Aircraft Propulsion
Object Number:
1962-341/1
Measurements:
overall: 200 mm x 1950 mm x 390 mm,
type:
blades
credit:
Airscrew-Weyroc Ltd.
