Combustion chamber for Heinkel-Hirth He 011

Details

Category:: Aircraft Propulsion

Object Number:: 1982-881

type:: combustion chamber

credit:: Cranfield Institute of Technology

Cite this page

Rights

We encourage the use and reuse of our collection data.

Data in the title, made, maker and details fields are released under Creative Commons Zero . Descriptions and all other text content are licensed under a Creative Commons Attribution 4.0 licence

Using our data

Download

Download catalogue entry as json

Download manifest IIIF

Our records are constantly being enhanced and improved, but please note that we cannot guarantee the accuracy of any information shown on this website.

Parts

Turbine for Heinkel-Hirth He 011 Combustion Chamber

Part of a Heinkel Hirth 001 Annular Combustion Chamber. Presumably the turbine for the combustion chamber. Object is a metal cylinder with two rows of metal spokes pointing away from the main cylindrical body.

Measurements:: overall: 325 mm x 520 mm

Materials:: metal (unknown)

Object Number:: 1982-881 Pt1

type:: parts

Image ©: The Board of Trustees of the Science Museum

Combustion Chamber Casing

Part of a Heinkel Hirth He 011 combustion chamber. Casing for the combustion chamber, possibly part of either the inner or outer casings. Object is a metal rectangle with eight metal spokes pointing away from the main body.

Measurements:: overall: 155 mm x 315 mm x 340 mm,

Materials:: metal (unknown)

Object Number:: 1982-881 Pt2

type:: parts

Image ©: The Board of Trustees of the Science Museum

Combustion Chamber Outer Ring With Small Mixing Fingers

Part of Heinkel Hirth He 011 Annular Combustion Chamber. Presumed to be the outer ring with small mixing fingers. Used to mix within the primary zone. Object is a metal circle with an even depth and multiple metal spokes or "fingers" set at an angle.

Measurements:: overall: 90 mm x 760 mm

Materials:: metal (unknown)

Object Number:: 1982-881 Pt3

type:: parts

Combustion Chamber Inner Ring With Small Mixing Fingers

Part of Heinkel Hirth He 011 Annular Combustion Chamber. Presumed to be the inner ring with small mixing fingers. Used to mix within the primary zone. Object is a thick slanted metal circle with multiple metal spokes or "fingers" set at an angle.

Measurements:: overall: 125 mm 660 mm,

Materials:: metal (unknown)

Object Number:: 1982-881 Pt4

type:: parts

16 Burners Within Combustion Chamber Component

Part of Heinkel Hirth He 011 Annular Combustion Chamber. Presumed to be the 16 burners with a combustion chamber component. Fuel is injected downstream through 16 burners. Object is a large metal cylinder with multiple spokes pointing towards the object. Inside on the lower section there are 16 circles.
