Turbine Disc

Turbine Disc

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Turbines disc blades for Bristol Siddeley Mamba gas turbine

Details

Category:
Aircraft Propulsion
Object Number:
1982-884
Measurements:
overall: 60 mm 410 mm,
type:
blades
credit:
Cranfield Institute of Technology
