Bendix-Stromberg Diaphragm Carburettor (injection)
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Bendix-Stromberg diaphragm carburettor (injection). Stamped: 70504, c. 1944
Details
- Category:
- Aircraft Propulsion
- Object Number:
- 1983-183
- Measurements:
-
overall: 1680 mm x 570 mm x 600 mm,
- type:
- carburetter
- credit:
- Cranfield Institute of Technology
