Replica of original Hertz apparatus in Deutsches Museum:- circular spiral resonator

Replica of original Hertz apparatus in Deutsches Museum:- circular spiral resonator

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Replica of original Hertz apparatus in Deutsches Museum:- circular spiral resonator, 21 cm diameter

Details

Category:
Radio Communication
Object Number:
1929-298
Measurements:
overall: 45 mm x 205 mm x 380 mm,
type:
replicas
credit:
Modellbauanstalt Munchen
