H.f. spectrum analyser type OA 1095 (serial no. 150)
- Made:
- 1951-1978
- maker:
- Marconi Instruments Limited
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
H.f. spectrum analyser type OA 1095 (serial no. 150) Post Office design, 1951, manufactured by Marconi Instruments Ltd., from 1958. Complete with spare CRT and Polaroid camera
Details
- Category:
- Radio Communication
- Object Number:
- 1978-4
- Measurements:
-
overall (Cathode ray tube 2 of 3): 740 mm x 340 mm x 355 mm,
overall (Spares box 3 of 3): 240 mm x 290 mm x 420 mm,
overall (analyser 1 of 3): 1310 mm x 600 mm x 850 mm,
- type:
- spectrum analyser
- credit:
- Home Office Radio Station
