Cleaneasy lubricator for gas exhauster

maker:
Bryan Donkin and Company
Cleaneasy lubricator for gas exhauster

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Cleaneasy lubricator for gas exhauster made by Bryan Donkin and Company

Details

Category:
Motive Power
Object Number:
1966-410
Measurements:
overall: 300 mm x 110 mm x 60 mm,
type:
lubricator
credit:
McColl, R.
