Wooden base

PART OF:
Pelton Wheel Turbine
Wooden base

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Wooden base

Details

Category:
Motive Power
Object Number:
1913-466/2
Materials:
wood (unidentified)
Measurements:
overall: 190 mm x 1045 mm x 687 mm,
type:
base
credit:
Dimes, C.W.
