Various machine parts from Hayes Store

PART OF:
Items found at Hayes Store

A quantity of machine parts found in Hayes bay 1 near to 1993-614; includes ratchet fittings, iron castings with slotted holes & a pair of cast gear wheels (one made-up to match the other) suggesting a textile machine

Details

Category:
Motive Power
Object Number:
1993-1593/24
Measurements:
overall: 340 mm x 710 mm x 480 mm,
type:
machine parts
