Recorder, depth sweeps pattern 8705
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Recorder, depth sweeps pattern 8705. This is a Royal Navy depth sweep recorder, a mechanical recording device used to log sonar or depth data.
Details
- Category:
- Oceanography
- Object Number:
- 1975-37
- Materials:
- steel (metal), paint, oil (unspecified), wood (unidentified) and brass (copper, zinc alloy)
- Measurements:
-
overall: 280 mm x 940 mm x 260 mm,
- credit:
- Southampton Oceanography Centre; Institute of Oceanographic Sciences, Deacon Laboratories
