Two pulleys and two belts mounted on cast iron frame to show Texrope drive
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Two pulleys and two belts mounted on cast iron frame to show Texrope drive
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1930-117
- Measurements:
-
overall: 380 mm x 220 mm x 560 mm,
- type:
- pulley
- credit:
- Frank Wigglesworth and Co., Ltd.
