Rolling mill bearings made from Bakelite laminated material

Rolling mill bearings made from Bakelite laminated material:- bearing machined from solid Bakelite material, wood housing representing worn metal housing, with dovetailed grooves fitted with Dovetailed grooves fitted with renewable strips of Bakelite material, separate thrust washer screwed in position, wood housing representing worn metal housing with one wide groove fitted with bearing of Bakelite Material

Details

Category:
Mechanical Power Transmission
Object Number:
1937-765
type:
mill
credit:
Bakelite Limited

Parts

Model illustrating journal bearing with strips and face fitted and machined

Model illustrating journal bearing with strips and face fitted and machined

Model illustrating journal bearing with strips and face fitted and machined

Object Number:
1937-765/1
type:
model
Model of shallow journal bearing brass filled with one piece of material and facing

Model of shallow journal bearing brass filled with one piece of material and facing

Model of shallow journal bearing brass filled with one piece of material and facing

Object Number:
1937-765/2
type:
model
Journal 'brass' made entirely of laminated material

Journal 'brass' made entirely of laminated material

Journal 'brass' made entirely of laminated material, broken in two along the lamination (marked pt 1 and pt 2)

Object Number:
1937-765/3
type:
journal brass
