D.B.S. 5" single reducing helical gear with cover
- Made:
- 1926
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
D.B.S. 5" single reducing helical gear with cover,
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1926-803
- Materials:
- steel
- Measurements:
-
: 9.8425 x 15.748 x 9.8425 in.; 250 x 400 x 250 mm
- type:
- gear wheels
- credit:
- David Brown & Sons (Huddersfield) Ltd.
