Flange probably from original driving gear (shaft on /3) and four fitted studs stamped up to match

PART OF:: Lead screw correcting lathe and accessories by Armstrong Whitworth and Co

Science Museum Group
© The Board of Trustees of the Science Museum

Flange probably from original driving gear (shaft on /3) and four fitted studs stamped up to match, each with 2 nuts

Details

Category:: Industrial Metrology

Object Number:: 1983-62/23

Measurements:: Fitted stud (per stud) x4: 42 mm x 122 mm x 42 mm,
Flange: 58 mm x 218 mm x 218 mm,

type:: flange
