Detail part of Priestman oil engine:- steel gauge

maker:
Priestman Brothers Limited
Detail part of Priestman oil engine:- steel gauge

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Detail part of Priestman oil engine:- steel gauge

Details

Category:
Heat Engines (non steam)
Object Number:
1914-410
Measurements:
overall: 32 mm x 32 mm x 332 mm,
type:
gauge
credit:
Priestman Bros. Ltd.
