Heinrici-type hot air engine

Heinrici-type hot air engine

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Heinrici-type hot air engine formerly used to power a petrol-air gas plant (27" high)

Details

Category:
Heat Engines (non steam)
Object Number:
1973-220
Measurements:
overall: 760 mm x 550 mm x 360 mm,
type:
engines
credit:
Scales, G.D.
