Sectioned cylinder head with air and exhaust valves
Sectioned cylinder head with air and exhaust valves
Cylinder head of the Ruston high compression airless atomiser oil engine
- Made:
- Lincoln
- manufacturer:
- Ruston and Hornsby Limited
Cylinder head of the Ruston high compression airless atomiser oil engine, in section, on wooden stand
Details
- Category:
- Heat Engines (non steam)
- Object Number:
- 1921-602
- type:
- cylinder
- credit:
- Ruston and Hornsby Limited
Parts
Fuel-injector with gasket ring (damaged) and cut-away gland
Fuel-injector with gasket ring (damaged) and cut-away gland, and small union pipe end
- Measurements:
-
overall: 81 mm x 155 mm x 232 mm,
- Object Number:
- 1921-602 Pt2
- type:
- fuel-injector
- Image ©
- The Board of Trustees of the Science Museum
Wooden stand and engraved brass label (damaged) on wooden board
Wooden stand and engraved brass label (damaged) on wooden board
- Measurements:
-
overall: 328 mm x 357 mm x 458 mm,
- Object Number:
- 1921-602 Pt3
- type:
- stand
- Image ©
- The Board of Trustees of the Science Museum
