Wade Bequest collection of valves: Catkin triode radio valve, by Marconi-Osram

PART OF:
Wade Bequest collection of valves
Made:
England, Germany and United States
maker:
Marconi Osram Valve Company Limited and Allgemeine Elektricitats-Gesellschaft
SMG00237618

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

SMG00237618
Science Museum Group
© The Board of Trustees of the Science Museum

Wade Bequest collection of valves: Catkin indirectly-heated triode radio valve, by Marconi-Osram. With B5 base and external copper anode. Paper label: W55.

Details

Category:
Electronic Components
Object Number:
1972-343/77
type:
valve
credit:
Wade, J.C.F.
