Wade Bequest collection of valves: Western Electric type 724B radio valve

PART OF:
Wade Bequest collection of valves
Made:
United States
maker:
Western Electric Company, Inc
SMG00237827

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

SMG00237827
Science Museum Group
© The Board of Trustees of the Science Museum

Wade Bequest collection of valves: Western Electric type 724B radio valve. Miniature disc-seal valve. No base.

Details

Category:
Electronic Components
Object Number:
1972-343/223
type:
valve
credit:
Wade, J.C.F.
