Cornering Stamping and Sizing Machine

The Monotype Corporation Limited

Buy this image as a print

License this image for commercial use at Science and Society Picture Library

Cornering Stamping and Sizing Machine
Science Museum Group
© The Board of Trustees of the Science Museum

Matrix corner de-burring, sizing and number stamping machine, Plant No.2888, made by The Monotype Corporation Ltd., Salford, Redhill, Surrey, 1964. Equipped for automatic feeding of matrix blanks from input to output galleys, part of the production system for 0.2 x 0.2-inch Monotype matrices. Mounted on bench

There are 82 separate processes needed to transform a designer’s drawing (of a letter, figure, punctuation, or symbol) into a piece of Monotype metal type for printing. A pantograph is used to trace and cut the letter from a copper pattern into a piece of steel called a punch. After being hardened, the punch is driven into a piece of bronze using a crank press to produce a matrix. The finished matrix is ready to go to the Monotype Composition Caster where molten metal is pumped through a mould against the matrix to produce a piece of type.

This machine is one of many machines used in the process to make a 0.2 inch or 0.4 inch matrix.

The Type Archive has a functioning Monotype matrix workshop containing around 70 machines and pieces of equipment. It is the only one of its kind in the world and matrices are still produced for customers.


Printing & Writing
Object Number:
aluminium alloy and steel (metal)
overall (bench): 890 mm x 2520 mm x 760 mm,
  • tools and equipment
  • equipment
