Seligman's plate heat exchanger
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Seligman's plate heat exchanger (first commercially available type, 1923) with 6 plates
Details
- Category:
- Industrial Chemistry
- Object Number:
- 1973-499
- Measurements:
-
overall each plate x6: 80 mm x 570 mm x 400 mm,
overall machine: 680 mm x 550 mm x 1180 mm,
- type:
- heat exchanger
- credit:
- Donated by Invensys APV.
