Milby Cut bridge girder, 1769

Milby Cut bridge girder, 1769

1769

Main Transverse Girder including King Post and Truss Girders from R.36

airship transverse girder

Length of main Longitudinal Girder, typical of H.M.A. R.38

airship longitudinal girder

Portion of Girder showing joint, from H.M.A. R.38, renamed Z.R.2.

airship portion of girder showing joint

Length of Intermediate Longitudinal Girder, typical of H.M.A. R.38

airship longitudinal girder

Length of Longitudinal Fin Girder from H.M.A. R.32

airship longitudinal fin girder

Arch girder 4 1/4" deep section, 1 length. Removed from museum mining display

Arch girder 4 1/4" deep section

Length of Intermediate Longitudinal Girder from L.33

airship intermediate longitudinal girder

Length showing joint of main Longitudinal and Intermediate Transverse Girder from L.33

airship longitudinal and intermediate transverse girder

Length showing joint of main Transverse Girder, typical of H.M.A. R.38

airship main transverse girder

3 Portions of girders constituting the framework of the Zeppelin, L.33, brought down at Wigborough, Essex, September, 1916

3 Portions of girders from Zepperlin L33 framework

Six arch girders 3 " deep with splayed flanges

Six arch girders 3 " deep with splayed flanges

Arch girder, channel section, 6 lengths on one pallet. Removed from museum mining display

Arch girder

Half section of cross girder: Composite double-skin plate girder (aka Box girder) of rivetted wrought iron plate with end piece of cast iron bolted to `L' section of plate.

Half section of cross girder

1848

Main girder: Composite double-skin plate girder (aka Box girder) of rivetted wrought iron plate with cast iron upper flange.

Composite double-skin plate girder

1848

Iron girder

Length of Intermediate Transverse Girder from H.M.A. R.32

airship intermediate transverse girder

Length of Longitudinal Girder from H.M.A. R.32

airship longitudinal girder

One arch girder 3 " deep with splayed flanges

One arch girder 3 " deep with splayed flanges

Arch girder, channel section, 1 length on one pallet. Removed from museum mining display

Arch girder

Arch girder 4 1/4" deep section, 68 lengths on four pallets. Removed from museum mining display

Arch girder 4 1/4" deep section

Cream-coloured metal girder component for the Buckton tensile tester (adapted later for compression testing), featuring a trapezoidal machine guide.

Metal Girder for Buckton Tensile Tester

1908

One Length Walking Way Girder from Schutte Lanz, airship 22

airship walking way girder

One Length Intermediate Longitudinal Girder, from Schutte Lanz airship 22

airship intermediate longitudinal girder

Length of Walking Way Girder from H.M.A. R.32

airship walking way girder

Length of main Transverse Girder from H.M.A. R.32

Airship main transverse girder
