Blackburn Tomtit aero-engine

Blackburn Tomtit aero-engine

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Blackburn Tomtit aero-engine

Details

Category:
Aircraft Propulsion
Object Number:
1985-187
Measurements:
overall (just engine): 520 mm x 730 mm x 500 mm,
overall (with stand): 1210 mm x 730 mm x 860 mm,
type:
engines
credit:
Gray, W.E.
