Turbine/Compressor Rotor for Gas Turbine
- maker:
- Rolls-Royce Limited
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Turbine/compressor rotor for Rolls-Royce/Griffith CR1 experimental gas turbine (one disc)
Details
- Category:
- Aircraft Propulsion
- Object Number:
- 1982-883
- Measurements:
-
overall: 40 mm 440 mm,
- type:
- rotor
- credit:
- Cranfield Institute of Technology
