Linear motor
- Made:
- 1948
- maker:
- Eric Roberts Laithwaite
This image is released under a CC BY-NC-SA 4.0
Licence
Buy this image as a print
BuyLicense this image for commercial use at Science and Society Picture Library
LicenseThis image is released under a CC BY-NC-SA 4.0
Licence
Buy this image as a print
BuyLicense this image for commercial use at Science and Society Picture Library
LicenseLinear motor, 1948
Science Museum Group
© The Board of Trustees of the Science Museum
SMG00224493
Science Museum Group
© The Board of Trustees of the Science Museum
Linear motor, 1948. The first linear motor built by Professor Laithwaite, for investigating the possibility of using linear motors to drive weaving shuttles. ( Stationary winding type)
Made of copper; softwood; steel; lead (solder); plastic covered wire; textile tape (impregnated around coils); paxolin (plasticand textile...)
Details
- Category:
- Electricity Supply
- Object Number:
- 1977-702
- Materials:
- copper (metal), wood (unidentified), steel (metal), lead (metal), plastic (unidentified), tape and paxolin
- Measurements:
-
overall: 77 mm x 803 mm x 95 mm, ,
- type:
- motor
- credit:
- Imperial College of Science & Technology
