A Model of an Evaporator

Made:
Derby
A Model of an Evaporator

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

A model of an Evaporator, typical of the type on a wooden base. Manufactured by Aitons of Derby and installed at Mexborough in 1945.

Details

Category:
Industrial Chemistry
Object Number:
YINP542
Measurements:
overall: 155 kg
type:
model of an evaporator
