Colchester Triumph 2000 lathe

Colchester Triumph 2000 lathe, 1971. The first production Triumph 2000 lathe was built in February 1968. The lathe was a revolution in styling and specification, with distinctive 'square' styling, ergonomically-designed controls and a bright exterior finish.The Triumph 2000 acquired a reputation as a robust, well-made lathe with a combination of capacity, speed and ease of use. This made it ideal as a general-purpose industrial lathe and, because of its modest price, it was also affordable by small machine shops and ambitious experienced amateurs.

Details

Category:
Hand and Machine Tools
Object Number:
1971-434
Measurements:
: in.
type:
lathe
credit:
600 Group

Parts

Colchester Triumph 2000 Lathe

Colchester Triumph 2000 Lathe

Lathe with tailstock, saddle with cross and top slides and complete with back toolport and copying attachment; 3 jaw chuck fitted. Also lifting eye fitted. Note : 1977-389 and 390 and 1982-1301 are fitted to this machine

Measurements:
overall: 1370 mm x 2100 mm x 760 mm,
Object Number:
1971-434/1
type:
lathes
Hydraulic Motor and Components for Colchester Triumph 2000 Lathe

Hydraulic Motor and Components for Colchester Triumph 2000 Lathe

Hydraulic Motor and Components for Colchester Triumph 2000 Lathe. Hydraulic motor, sump and supply lines for power feed of lathe cross feed

Measurements:
overall: 660 mm x 340 mm x 780 mm,
Object Number:
1971-434/2
type:
motor
Splash Guard for Colchester Triumph 2000 Lathe

Splash Guard for Colchester Triumph 2000 Lathe

Splash guard

Measurements:
overall: 330 mm x 1300 mm x 630 mm, 16.5 kg
Object Number:
1971-434/3
type:
splash guard
Chuck Guard for Colchester Triumph 2000 Lathe

Chuck Guard for Colchester Triumph 2000 Lathe

Chuck guard (glass fibre)

Measurements:
overall: 220 mm x 230 mm x 250 mm, 1.5 kg
Object Number:
1971-434/4
type:
chuck guard
Components for Colchester Triumph 2000 Lathe

Components for Colchester Triumph 2000 Lathe

A further chuck guard (broken), eight anti vibration pads (for supporting the lathe), plug for tapped hole for crane lifting point

Measurements:
overall: 460 mm x 600 mm x 930 mm, 25.5 kg
Object Number:
1971-434/5
type:
components
Faceplate

Faceplate

Faceplate

Object Number:
1971-434/6
type:
faceplate
4 jaw chuck and key

4 jaw chuck and key

4 jaw chuck and key

Object Number:
1971-434/7
type:
chuck
2 plain centres

2 plain centres

2 plain centres, rotating centre, adaptor for mandrel nose and 3 outside jaws for 3 jaw chuck (fitted to machine)

Object Number:
1971-434/8
type:
plain centres
Catch plate with pin

Catch plate with pin

Catch plate with pin

Object Number:
1971-434/9
type:
catch plate
Collet chuck with 14 collets and pin spanner

Collet chuck with 14 collets and pin spanner

Collet chuck with 14 collets and pin spanner

Object Number:
1971-434/10
type:
chuck
Fixed 3-point steady

Fixed 3-point steady

Fixed 3-point steady

Object Number:
1971-434/11
type:
steady
2 point travelling steady

2 point travelling steady

2 point travelling steady, back toolpost block, topslide toolpost block and 6 fittings for tooling and 4 keys (2 sets of 2)

Object Number:
1971-434/12
type:
steady
Standard parts removed to fit elaborations

Standard parts removed to fit elaborations

Standard parts removed to fit elaborations, cross-slide screw and divided nut, screw cutting dial on bracket, cross-slide handwheel on bracket

Object Number:
1971-434/13
type:
parts
Oil cans

Oil cans

Oil cans

Object Number:
1971-434/14
type:
oilcans
