C.N.C. Coordinate measuring machine model FN - 403

C.N.C. Coordinate measuring machine model FN - 403 ; one System complete with some duplication of some parts with later equipment.

Clear all filters
Category
Maker
Object type
Place
Material
Date
Tilting platform for the additional monitor for the co-ordinate measuring machine.

Tilting platform for the additional monitor for the co-ordinate measuring machine

circa 1982
Rotating table for mounting the 2 disc drive unit part 16.

Rotating table for mounting the 2 disc drive unit part 16

circa 1982
Table to be placed on the swivelling arm support on the main unit of the co-ordinate measuring machine.

Mounting table

circa 1982
Two cardboard boxes & one paper packet of continuously folded lined paper for a sprocket drive printer.

Paper accessories

circa 1982
Fixture plate for the workpiece with origin gauging point attached to enable base points to be established for use with the Mitutoyo co-ordinate measuring machine.

Fixture plate

1983
Probe and probe holder fitting into the probe socketof the Mitutoyo co-ordinate measuring machine.

Probe and probe holder fitting into the probe socketof the Mitutoyo co-ordinate measuring machine

1983
Supporting stand on four castors for supporting the CRT, printer or keyboard of the Mitutoyo measuring machine.

Supporting stand on four castors for supporting the CRT

1983
Main measuring unit of the Mitutoyo Coordinate measuring machine, model FN - 403 ;

Main measuring unit of the Mitutoyo Coordinate measuring machine

A 2 drawer steel cabinet with 'formica'work top for storage and supporting the ancilliary equipment of the Mitutoyo coordinate measuring machine.

2 drawer steel cabinet

1983
Stand for the printer for the Mitutoyo Coordinate Measuring machine; with pull out drawer.

Stand for the printer for the Mitutoyo Coordinate Measuring machine

Stand for main measuring unit of the Mitutoyo Coordinate measuring machine, model FN - 403 ;

Stand for main measuring unit of the Mitutoyo Coordinate measuring machine

A machined workpiece being a suitable sample for demonstrating the operation of the Mitutoyo coordinate measuring machine being a machined aluminium head of a 3 cylinder combustion engine.

Machined workpiece

1983
Querty electronic keyboard with lead and plug with integral copy and output lamps for use with the Mitutoyo coordinate measuring machine.

Querty electronic keyboard

1983
Loose sheet steel panel to fit to the front of the main unit stand (part 2) of the Mitutoyo coordinate measuring machine.

Loose sheet steel panel

Loose sheet steel panel to fit the rear of the main unit stand (covering the air set) of the Mitutoyo coordinate measuring machine, part 2.

Loose sheet steel panel

110 volt mains supply cable to the main unit of the co-ordinate measuring machine, one end tagged C. M. M. the other tagged P1.

110 volt mains supply cable to the main unit of the co-ordinate measuring machine

circa 1982
Multi-core cable approx 5 metres long for the connection of Pt 15 servo unit to the main co-ordinate measuring machine.

Cable for co-ordinate measuring machine

circa 1982
Original Servo Unit, replaced by Mitutoyo Engineer, c. 1987

Original Servo Unit

1987
Stand for control box of /1

Stand for control box of /1

Original Data Control Unit and Control Box (connected together by cable) together with other cables connected to Unit. Replaced by Mitutoyo Engineer, c. 1987

Original Data Control Unit and Control Box

1983
Two transformer units associated with 1983-1178 Pts 28 and 30, by Onoden Co

Two transformer units

Two disc Mitutoyo drive unit with connecting lead for use with the Mitutoyo cordinate measuring machine.

Two disc Mitutoyo drive unit

circa 1982
Additional or alternative C.R.T. monitor for the co-ordinate measuring machine; this part may not belong to this main object.

Additional or alternative C.R.T. monitor for the co-ordinate measuring machine

circa 1982
Three heavy mult-core cables tagged X, Y and Z, to fit respectively tagged connection sockets on the main unit, part 1, of the co-ordinate measuring machine.

Three heavy mult-core cables tagged X

circa 1982
C.R.T. monitor unit for use with the co-ordinate measuring machine.

C.R.T. monitor unit for use with the co-ordinate measuring machine

circa 1982
Probe, CMM series 14 for use with the Mitutoyo co-ordinate measuring machine consisting of block with ground faces, ball ended probe with male screw thread, bolt andwasher and a allen key.

CMM series 14 probe

1983
Wooden box with padded inside containing three similar shaped but differing thickness stampings.

Wooden box with padded inside containing three similar shaped but differing thickness stampings

1983
Foot operated switch type OFL-VG-S3 made by Jiden of Osaka, still in its cardboard delivery box for use with the Mitutoyo coordinate measuring machine.

Foot operated switch type OFL-VG-S3 made by Jiden of Osaka

1983
Servo unit for Mitutoyo co-ordinate measuring machine.

Servo unit for Mitutoyo co-ordinate measuring machine

1983
Printer unit for use with the Mitutoyo co-ordinate measuring machine.

Printer unit for use with the Mitutoyo co-ordinate measuring machine

circa 1982
Input/output signal cable plugs from the main unit of the co-ordinate measuring machine to the servo unit part 15.

Signal cable plugs

circa 1982
