Bourdon pressure gauge

Bourdon pressure gauge

Bourdon pressure gauge

Bourdon pressure gauge

Metal manometer pressure gauge

Metal manometer pressure gauge

Caisson gauge, calibrated for heat, 1940

Caisson gauge, calibrated for heat, 1940

1940

Pressure gauge

Pressure gauge

1856-1862

Recording Pressure Gauge

Recording Pressure Gauge

1873

Ferranti water pressure gauge

Ferranti water pressure gauge

Horlicks Mcleod gauge

Horlicks Mcleod gauge

Unknown date

Aircraft engine back pressure gauge 0-20 psi

Aircraft engine back pressure gauge 0-20 psi

1916

Steam pressure test gauges used at Bankside Power Station

Steam pressure test gauges used at Bankside Power Station

Pressure Gauge

Pressure Gauge

Pressure gauge used with Berthelot-Mahler Bomb Calorimeter

Pressure gauge used with Berthelot-Mahler Bomb Calorimeter

1889

Pressure Gauge by Finney in Carved Mahogany Frame

Pressure Gauge by Finney in Carved Mahogany Frame

1760-1772

3 Pointers from Pressure Gauge by Finney

3 Pointers from Pressure Gauge by Finney

1760-1772

Pressure Gauge for Polyethylene Apparatus.

Pressure Gauge for Polyethylene Apparatus.

Schaffer & Budenberg steam pressure indicator

Schaffer & Budenberg steam pressure indicator

Pressure gauge, Bourdon type, glazed face to show mechanism, scale 0-12 kg/cm2, for demonstration / exhibtion, by Schaffer & Budenberg, Magdeburg, Germany, c. 1890, mounted on marble, presented to Charles King, British locomotive engineer employed in Europe, 1866-1946. [Details on file]

Bourdon type pressure gauge

circa 1890

Fitted wooden case containing: oxygen pressure gauge, calibrated 0-180 atmospheres and 1-10 Cuft. By Schaffer and Budenburg, Manchester. Also with: Beard's oxygen regulator (converted 1934 to high pressure for injector jet - see 1990-5036/0229) and fitting for connection of gauge to cylinder; regulator to cylinder and gauge regulator to cylinder.

Oxygen pressure gauge and fittings

Pressure gauge, Bourdon, North British Railway, made by Schaffer & Budenberg of Manchester and Glasgow. Overall: 305 mm x 227 mm x 50 mm.

Bourdon pressure gauge, North British Railway

Steam pressure indicator; in wooden box (lid is detached). Have gauge and two parts in box. Maufactured by W Carey Hargreaves

Steam pressure indicator

circa 1940

Pressure gauge for oxygen cylinder, calibrated in atmospheres and cubic feet (for lo cu. Ft. bottle). By Schaeffer and Budenberg Ltd, Broadheath, nr. Manchester.

Oxygen pressure gauge

Base pressure gauge; brass with a glass face, manufactured by Schaeffer & Budenberg

Base Pressure Gauge

Inlet Manifold Pressure Gauge (?) By J.C. Eckardt, Stuttgart. Bauart: R. Fuess 186. Gerat Nr. 127-1052 A. Anforderz FL 20555

Inlet manifold pressure gauge

1920-1970

Pressure gauge in pine case, R.18077, by Negretti & Zambra, London

Pressure gauge in pine case

1960-1968

Pressure gauge (No.1768257), manufactured by Schaffer & Budenberg. Contained in wooden unit with electrical fuses manufactured by Brush Electrical Engineering Co. Ltd.

pressure gauge

Pump suction and delivery pressure gauges mounted on cast iron plate.

Pump suction and delivery pressure gauges

1939

Beard's oxygen pressure gauge and regulator. Oxygen gauge calibrated 0-180 atmospheres with Beard's patent regulator 17633.

Beard's oxygen pressure gauge and regulator

1880s

Oxygen pressure gauge, calibrated 0-180 atmospheres and 1-10 Cuft. By Schaffer and Budenburg, Manchester.

Oxygen Pressure Gauge and Fittings

Bourdon pressure gauge made by Tinser's of Hyde.

Bourdon pressure gauge made by Tinser's of Hyde

Beard's hydrogen pressure gauge and regulator. Hydrogen gauge calibrated 0-180 atmospheres with Beard's patent regulator 17633.

Beard's hydrogen pressure gauge and regulator

1880s

Budenberg pressure gauge for gas cylinder. 0-200 atmospheres, 0-10 cubic feet (for 1ocf bottle). Budenberg Gauge Company.

Budenberg Pressure Gauge

Pressure Gauge, brass cased, Bourdon Gauge with dial removed to show internal workings.

Pressure Gauge, Bourdon Gauge

Beard's pressure gauge and regulators for oxygen and hydrogen cylinders. Oxygen gauge calibrated 0-180 atmospheres with Beard's patent regulator 17633. Hydrogen gauge calibrated 0-180 atmospheres with Beard's patent regulator 17633. In wooden box.

Beard's pressure gauge and regulators for oxygen and hydrogen cylinders

1880s

Pressure Gauge, Marked Robert Stephenson & Hawthorns. Calibrated up to 320lb/sq".

Pressure gauge, Robert Stephenson & Hawthorn

1942
